John Deere Hay & Forage Mowing EquipmentSickle Bar Mowers
Adjustable skid shoes
The adjustable skid shoes on the cutterbar make it easy to control the working height of Frontier™ sickle-bar mowers.
The cutter blades on the Frontier™ sickle-bar mowers are belt driven with a manual adjustment for tension.
The enhanced breakaway mechanism has been strengthened on the SB31 Series Sickle-Bar Mowers for improved cutterbar protection and longer machine life.
The redesigned cylinder stop can be raised from the operator station by a cable and attached pull rope. This allows the operator to raise the cutterbar fully to move around obstacles without leaving the tractor seat.
The bolt-on cutterbar knife guards and the riveted sections on the Frontier™ sickle-bar mowers can be removed and replaced individually.
| Working width | 235 cm 92.5 in. |
|---|---|
| Minimum cutting height | 2.5 cm 1 in. |
| Maximum cutting height | 7.6 cm 3 in. |
| Shipping weight | 303.5 kg 669 lb |
|---|---|
| Operational weight | 246.3 kg 543 lb |
| PTO minimum hp | 18.6 kW 25 hp |
|---|---|
| PTO maximum hp | 37.3 kW 50 hp |
| PTO rpm | 540 rpm |
| Type | 3-point, Category 1, Category 2 |
|---|---|
| iMatchTM compatible | Yes |
| Quick-coupler compatible | Yes |
| Labor hours | 4 |
|---|
| Time period | 1 year |
|---|
| Date collected | - |
|---|
